    FWDM T x 1550nmCWDM Mux Demux 20dB Metal Tube Isolation For Line Monitoring

    Ask Lasest Price
    Brand Name : J&K
    Model Number : FWDM
    Certification : UL; SGS; ROHS
    Price : Negotiation
    Payment Terms : L/C, T/T
    Delivery Time : 3~5days
    • Product Details
    • Company Profile

    FWDM T x 1550nmCWDM Mux Demux 20dB Metal Tube Isolation For Line Monitoring

    FWDM Tx1550nm RX1310/1490nm with metal tube Isolation >20dB


    Sino Fibre Optic Co.,Ltd. is a manufacture company more than ten years,our factory locates at Shenzhe,it's dust-free.

    We're specalize in fiber optic product manufacture,to help our customers get accurate products they want and dedicated pre-sales and after-sales services.


    Applications:

    • Line monitoring
    • WDM system
    • Triple-Play FTTH
    • Telecommunication network system

    Features:

    • Flat and wide bandwidth
    • Low insertion loss
    • High stability and reliability
    • high channel isolation
    • Epoxy-free optical path

    Specifications:


    ModelFWDM-1*2
    Passband Central Wavelength nm1550
    Reflective Band Central Wavelength nm1310&1490
    Passband Wavelength nm1530~1620
    Reflective Band Wavelength nm1260~1360&1450~1520
    Insertion LossTransmission 1550nm dB0.60
    Reflection 1310nm dB0.40
    Reflection1490nm dB0.40
    IsolationTransmission 1310nm dB>50
    Transmission 1490nm dB>35
    Reflection 1550nm dB>20
    PDL dB≤0.1
    Return Loss dB≥60
    Directivity dB≥55
    Fiber Length m1.0
    Operating Temperature ℃-10~+70
    Storage Temperature ℃-40~+85
    Dimensions mm34*Ø5.5 & 90x20x10
    Fiber TypeSM,9/125,900um

    FWDM Tx 1550nm CWDM Device 20dB Metal Tube Isolation For Line MonitoringFWDM Tx 1550nm CWDM Device 20dB Metal Tube Isolation For Line Monitoring
