Single Mode Corning Fiber Patch Panel 1260 - 1650nm Wavelength Custom Design

    Buy cheap Single Mode Corning Fiber Patch Panel 1260 - 1650nm Wavelength Custom Design from wholesalers

    Buy cheap Single Mode Corning Fiber Patch Panel 1260 - 1650nm Wavelength Custom Design from wholesalers
    • Buy cheap Single Mode Corning Fiber Patch Panel 1260 - 1650nm Wavelength Custom Design from wholesalers

    Single Mode Corning Fiber Patch Panel 1260 - 1650nm Wavelength Custom Design

    Ask Lasest Price
    Brand Name : J&K
    Model Number : fiber patch panel
    Certification : Rohs
    Price : Negotiation
    Payment Terms : L/C, T/T
    Delivery Time : 3~5days
    • Product Details
    • Company Profile

    Single Mode Corning Fiber Patch Panel 1260 - 1650nm Wavelength Custom Design

    coning fiber patch panel, custom fiber optic cable assemblies, single mode and multimode fibe


    Features


    • Available for 1*2,1*4,1*8,1*16,1*32,1*64,1*128 and 2*2, 2*4, 2*8, 2*16, 2*32, 2*64 configurations
    • With different connectors: LC, SC, FC, etc.
    • Available for different packages: Blockless, Steel tube, ABS box, LGX box, Insert-type, Pallet Type,19" Rack Mount
    • Low insertion loss and low PDL
    • Excellent uniformity over a wide wavelength range from 1260nm to 1620nm
    • Working in temperature from -40C to +85C
    • Fully comply with Telcordia GR-1209-CORE and Telcordia GR-1221-CORE


    Applications

    • FTTx (FTTB, FTTH, FTTC)
    • Low PDL Passive Optical Networks (PON)
    • High Return Loss Local Area Networks (LAN)
    • Uniform Power Splitting CATV Systems
    • Compact Design Test Equipment

    Specifications


    Custom Single Mode Corning Fiber Patch Panel With 1260-1650nm Wavelength

    Custom Single Mode Corning Fiber Patch Panel With 1260-1650nm Wavelength
